KONE UniDrive®
Upgrade the control element of any brand of automatic sliding door in just a few hours – with no changes to the door construction – for improved safety, reliability, and efficiency.
KONE UNIDRIVE® SLIDING DOOR OPERATORS
We offer two operators for sliding doors: the KONE UniDrive for doors in high-traffic environments and the KONE UniDrive Compact for less demanding applications. We also offer the all new KONE UniDrive kit for fast, cost-effective modernization of almost any brand of sliding door operator.
All new KONE UniDrive modernization kit for sliding door operators
Description
A smart solution that can be used to modernize KONE or third-party door operators, avoiding the need to replace the entire door unit. Modernizing the operator extends the life of the door and ensures safe operation.
Specification
- Space required: 85x75 mm
- Max. door opening width: up to 5000 mm depending on application
- Compatible with most types of sliding door*
- Max door leaf weight: single doors 180 kg (270 kg optional), double doors 120 kg per leaf (180 kg per leaf optional)
*Consult your local sales representative
Benefits
- Cost-effective upgrade with minimal downtime
- Suitable for a wide variety of building types
- Quiet operation
- Ensures that the door operator meets the latest safety, reliability, and eco-efficiency standards
- Provides foundation for future cloud connectivity
Watch the video
Sliding door operators product information
The KONE UniDrive and KONE UniDrive Compact sliding door operators both feature customizable operation, easy maintenance and adjustment, and building management system integration, as well as compliance with relevant safety and reliability standards.
| KONE UniDrive® | KONE UniDrive® Compact | |
|---|---|---|
| Dimensions (height x depth) | 185 x 161 mm | 130 x 133 mm |
| Max. opening width 1-leaf/2-leaf | 5000 mm (depending on application) | 1 x 1500/ 2 x 1000 mm |
| Max. door leaf weight 1 leaf/2 leaf | 1 x 180 / 2 x 120 kg (option: 1 x 270/2 x 180 kg) | 1 x 100/ 2 x 80 kg |
| Max. opening/closing speed | 0.7 m/s | 0.53 m/s |
| Exterior door | x | x |
| Interior door | x | x |
| High use frequency | x | x |
| Standards compliancy | x | x |
| Break-out function | x
Mechanical and battery back-up system | x
Battery back-up system |
| Eco-efficiency | x | x |
| Escape and rescue route electrical | x
Fail/Safe RW | |
| Fire protections, telescopic, curved, prismatic options
| x |
